Unit Price:$30.00
Model No.︰ PA6-800-35U
Brand Name︰OEM
Country of Origin︰USA
Added time:2013-11-08

Quantity

Product Details

Technical Specifications

Mains Voltage: 110/240VAC

Mains Frequency: 50/60Hz

Power Factor: >0.98

Efficiency: >90%

Operating Frequency: 40-60KHz

Dimensions: 135*60*30mm

Installation Requirement

Wire Gauge: 0.5-1.0mm²

Max. cable length between ballasts and lamp: 5m

LED specification: V_f=1.8-3.6V I_f=5-20mA

Mounting Restrictions

Disconnect Input Power Before Installing or Servicing.

Ballast Case Must Be Grounded.

Don’t short any two wires of the four outputs.

Features

Starting: Preheat

Lamp status indication via DC signal output

DC 5V±5% （5mA）: lamp on.

DC 0V: lamp fault or no lamp.

Connect LED.

Applications

All areas of applications include UV lamps.

Air purification

Medical treatment

Type

Input Voltage (V)

Input Power

(W)

Input Current (A)

Power Per Lamp

(W)

Lamp Current (A)

Weight (kg)

PA6-800-35U

99-264

41-56

0.52A@110V

0.24A@240V

35-48

0.75-0.85

0.17
